SW-K GAMMA Aluminium console-mounted rope winch

 Image manuel winch GAMMA 200kg
Image manuel winch GAMMA 500kg
Image manuel winch GAMMA-800kg
 Image manuel winch GAMMA 200kg
Image manuel winch GAMMA 500kg
Image manuel winch GAMMA-800kg

Capacity: 200 - 800 kg. Suitable for outdoor use due to robust construction, from 500 kg. load capacity with high-speed gear for small loads and faster winding and unwinding of the unloaded rope.

Features and Benefits

The alu console-mounted wire rope winch SW-K GAMMA is suitable for use outdoors with its robust build.

Equipment and processing

Carrying loads 200 - 800 kg

  • Compact aluminum housing and closed chain drive
  • As of 500 kg carrying load with fast gear for small loads and faster coiling and uncoiling of the unloaded rope
  • Smoothly running spur gear for high efficiency
  • Low-friction shaft with plain bearings for better rope unwinding and a longer service life of the winch
  • Wide rope drum for large rope holder and two rope attachments
  • Simple and quick attachment
  • Integrated safety spring brake system and removable hand crank
  • Winch can be operated from either side



Pfaff-silberblau - manual and electric wire rope winches

Our wire rope winches can be used in various applications. Discover in this short clip the possibilities that our winches open up.

Pfaff-silberblau - product overview lifting and motion technology

We are technology leaders in components and system solutions for mechanical motion and lifting technology.

Our product portfolio includes #screwjacks, #linearmotion, #liftingcolumns, #liftingtables, #electric and #manuel #wireropewinches, #screws, #nuts, #bevelgear boxes and #accessories.
