VOLTAGE: 12 VDC
SCREW TYPE: Acme ScrewSTANDARD STROKE: 3 to 18 in (76 to 457 mm)
TEMPERATURE RANGE: 15ºF to 120ºF (-10ºC to 50ºC)
TUBE RESTRAINING TORQUE: 215 in-lbf (24.2 Nm)
ENVIRONMENTAL RATING: IP50 protection standard (IP52 optional)
FEATURES and BENEFITS:
Heavy duty design for long life in tough applications
Bi-directional spring brake
Aluminum housing and outer tube
Steel translating tube – zinc chromate plated
Double clevis mounting
Internal adjustable limit switches (LSPD Series)
OPTIONS
Potentiometer
Weather resistant sealant – IP52
Bellows boot
Trunnion mounting
Threaded end
