Lineman's Strap Hoist

Little Mule Strap Hoist 300A Image
Little Mule 344C Image
Little Mule Strap Hoist 300A Image
Little Mule 344C Image

The Little Mule Lineman's Strap Hoist is high quality and dependable, making it one of the favorites of linemen across the nation. This strap hoist is designed for rugged use with dependability in mind.

Buy Now

Features and Benefits

Explore Features of the Little Mule 344C Lineman's Strap Hoist

Designed for safety and dependability

Explore the features of the Little Mule 344C Lineman's Strap Hoist, the preferred hoist of utility industry professionals. Little Mule helps you get the job done and home safe – even in the most hazardous environments.

Watch Video
344C Strap Hoist Video

Features and Benefits

Non-Conductive Handle

Fiberglass handle with polyester webbing provides added non-conductive material when using proper hot line handling techniques. Some models also available with hot stick ring on handle.

Overload Feature

Solid fiberglass handle, with replaceable tips, bends to alert operator of a possible overload.

Hooks and Gate Latches

All hooks swivel 360° and are equipped with latches. Optional hooks with gates can also be added.

Positive Load Holding

Double interlocking pawls assure one pawl is engaged at all times. Dual pawl springs provide unsurpassed reliability.

Safe Design

Thumbscrews used to secure the handle are pegged and cannot be backed out. Competitive units use butterfly nuts which can cause the handle to come loose.

Open Design

The open design allows for easy inspection and cleaning.

Lightweight and Rugged

These hoists are made with cast aluminum frames as well as corrosion-resistant stainless steel springs and frame shafts. Roller shafts are stainless steel plated. All rotating shafts are mounted on bronze bushings for reduced wear.

Easy Load Positioning

Utilizing a double pawl system, this multiple pawl stops for precise load adjustment.

Easy to Operate

Self-storing web drum provides compact operation. Non- conductive winding wheel provided for quick take-up or positioning of slack webbing.

4:1 Design Factor

Meets or exceeds minimum 4:1 design factor and all requirements of ASME/ANSI Standard B-30.21. All units tested at 125% of rated load.

Adjustable Capacity Hoist Option

Double-reeved hook block configuration increases capacity. Easily removable sheave block with a quick disconnect design allows the hoist to be converted for double or single-line use.

Models Available


MODEL 250A

1 ton Capacity

Standard Hooks & Safety Latches

Hook Options:

  • Hot Stick Ring Hook with Safety Latch (250DA)
  • Standard Hook with Heavy-Duty Swivel Gate with Latch (250CA)
  • Hot Stick Ring Hook with Hot Stick Ring Hook Safety Latch (250HA)


MODEL 300A

1-1/2 ton Capacity

Standard Hooks & Safety Latches

Hook Options:

  • Hot Stick Ring Hook with Safety Latch (3000DA)
  • Standard Hook with Heavy-Duty Swivel Gate with Latch (300CA)
  • Hot Stick Ring Hook with Hot Stick Ring Hook Safety Latch (300DHA)


MODEL 322C

1-1/2 ton Capacity

Standard Hooks & Safety Latches

Hook Options:

  • Hot Stick Ring Hook with Safety Latch (322DC)
  • Standard Hook with Heavy-Duty Swivel Gate with Latch (322CC)
  • Hot Stick Ring Hook with Hot Stick Ring Hook Safety Latch (322DHC)


MODEL 344C

2 ton Capacity

Standard Hooks & Safety Latches

Hook Options:

  • Hot Stick Ring Hook with Safety Latch (344DC)
  • Standard Hook with Heavy-Duty Swivel Gate with Latch (344CC)
  • Hot Stick Ring Hook with Hot Stick Ring Hook Safety Latch (344DHC)


MODEL 6000A

3 ton Capacity

Standard Hooks & Safety Latches

Hook Options:

  • Hot Stick Ring Hook with Safety Latch (6000DA)
  • Standard Hook with Heavy-Duty Swivel Gate with Latch (6000CA)





How To Properly Inspect Your Lever Strap Hoist

When using a lever strap hoist, it’s important to inspect it regularly to prevent accidents or product failures. These inspections are broken down into frequent and periodic inspections.
