BETA-SL Electric wire rope winch

Short times to delivery are followed by long periods in operation: the electric wire rope winch BETA-SL in its standard design works permanently reliably due to enclosed worm gear pairs or spur gears with high-quality brake motors. The electric wire rope winches BETA SL are available with a contactor control system including a gear limit switch.

Equipment and processing

• Load capacity 250 - 2000 kg
• Maintenance-free worm gear pairs or low-maintenance spur gear with milled and ground gears – running in oil bath
• Very quiet running by diagonal interlock
• Electrically released spring-applied disc brake
• Duty ratio S3 – 40 %
• Range of temperature: -20 °C - + 40 °C
• Powerful three-phase motor for multi-range voltage 380 – 420 V / 50 Hz or 440 – 460 V / 60 Hz
• Motor protection type IP 55
• Grooved wire rope drum
• Large wire rope capacity
• Contactor control 42 V
• Gear limit switch
• Electronic overload protection as of 1000 kg lifting load
• According to the accident prevention provisions DGUV V54 (BGV D8)
• Options selectable
