Intelli-Connect Wi-Fi Retrofit Kit With Cord Image

Intelli-Connect™ Mobile

Intelli-Connect

The analytical and diagnostic capabilities of Intelli-Connect™ provide information on the status of the system, whether you use a smart phone or a tablet, to help you administer the equipment 24 hours a day, 7 days a week .

Intelli-Connect™ Brochure (English) Intelli-Connect™ Wireless Operator Installation Guide - 144-11965 (English) Intelli-Connect iOS Keypad Intelli-Connect Wireless Operator Downloads Page Intelli-Connect Mobile FAQ

Intelli-Connect Mobile
WOP-20	WOP-20 Kit	WOP-EXT

Plugs into Series 4 VFD Operator Port	Ideal for New Panels. Comes with Flush Panel mount kit including both 1-meter and 3-meter cable	Ideal for Retrofit Panels that do not have an exsitng panel mount kit. 0 Meters = No Cable 1 Meter = 1-meter Cable 3 Meter = 3-meter cable
Cables not included	Standard ethernet patch cable	Standard ethernet patch cable

FEATURES and BENEFITS:

INFORMATION AT YOUR FINGERTIPS

Intelli-Connect Mobile’s wireless drive monitoring, analytics, and configuration capabilities deliver system status information, whether you’re using a smartphone or tablet, to help you manage equipment 24/7. You can get insight into how your systems operate and how your equipment is utilized to ensure proper and timely maintenance.

IMPROVED SAFETY

Using Intelli-Connect Mobile, you can monitor and troubleshoot a Magnetek variable frequency drive (VFD) right from the plant floor. Intelli-Connect Mobile wirelessly connects to crane equipment located 20-100 feet in the air, allowing you to safely and quickly get an overview of your system’s operation. You no longer need to power down the crane, climb up to the drive, and connect hardware to access drive information, eliminating potentially hazardous situations.

QUICK TROUBLESHOOTING AND RECOVERY

Intelli-Connect Mobile provides critical information, such as signal monitors, run trending data, equipment usage history, and event history. By incorporating this technology into your overhead crane or hoist, you can proactively monitor and schedule maintenance to ensure you have the necessary parts and support available when you need it. And, if your system does go down unexpectedly, Intelli-Connect Mobile can help reduce your mean time to recover (MTTR). With instant access to user manuals available through the app, operators can easily reference system setup and diagnostics to get equipment back up and running quickly.

One-to-one connection from App to IMPULSE*G+/VG Series 4 and G+ Mini VFDs.
CM HI-Tech PC interface.
Monitoring of VFD Current, Torque, Digital I/Os, etc.
Fault Reset.
Read and Write Critical Parameters (Quick Access).
Operator Emulator Mode (LCD and Buttons).
Upload and Download VFD Parameter Files (Compatible with IMPULSE*Link 5).
Documentation Access (User Manuals, Quick Star Guides, Installation Guides, FAQ, etc.).
Secure Wi-Fi Connection: Customize SSID Name and Password.
Trending and Event History Log Files (Compatible with IMPULSE*Link 5).
Maintenance and Inspection Log.
